Wind combination sensor USA

Ultrasonic anemometer to measure wind velocity and wind direction

Get product information here:

Enquire now

Compact combination sensor to measure wind velocity and wind direction at weather stations. Due to ultrasound technology sensor has no moving parts and is therefore very robust and low-maintenance

  • Robust and low-maintenance design, no moving parts
  • Low power consumption
  • Operates down to -52°C with optional heating
  • Simple assembly
Wind velocity: 0 to 60 m/s; 0.1 m/s; ±3% at 10 m/s (Measuring range; resolution; accuracy)
Wind direction: 0 to 360°; 1°; ±3° (Measuring range; resolution; accuracy)
Output signal: Digital SDI -12, RS-232, RS-485, RS-422
Input voltage: 5 to 32 VDC
Power consumption: 3 mA at 12 VDC
Dimensions: 139 x 114 mm (height x diameter)
Weight: 510 g
